AN61 5mm Aluminium Stair Nosing Raked-Back Single Channel 62mm Tread

✓ In Stock

5mm gauge aluminium – strong and durable construction
Raked-back profile – enhanced step definition
62mm tread / 32mm nose – excellent coverage
Multiple infill options – PVC, Aluminium & Olympic Grip
Designer Bronze & Light Bronze finishes available

AN61 Datashet

Catalogue Reference	AN61BA
Uniclass2015	Pr_35_90_31_74 RIGID STAIR NOSINGS
General Description	Single Channel/Raked Front Stair Nosing. Supplied with choice of infill.
Nosing Construction	Stair Nosing With Infill
Material	Aluminium Alloy 6063 T6
Tread Dimension	62 mm
Nose Dimension	32 mm
Gauge	5.0 mm
Supplied Cut To Size, up to a maximum length of	2700 mm, 2750 mm, 3200 mm
Screw Size	8
Compatible Products	ANEXT, ANRE25
Application	ANRE25 Ramp Detail and ANEXT extension tread installation guide available. Suitable for stairs with low to medium traffic volumes where heavy foot traffic and impacts may cause wear., flush in wooden steps. Compatible with profiles ANE Nap Detail
Suitability	through the finish to reveal the natural aluminium colour beneath.
Post Consumer Recyclability	This product is 100% recyclable at suitable disposal centres.
Profile Type	Stair Nosing

Price range: £30.45 through £86.45 inc. VAT

ex. VAT £25.38-£72.04

Finish

Colour

Clear

AN61 Aluminium Stair Nosing is a premium 5mm gauge, raked-back, single-channel stair nosing designed to provide durable edge protection and enhanced step definition in commercial and residential environments.

Manufactured from Aluminium Alloy 6063 T6, the AN61 features a 62mm tread and 32mm nose, delivering excellent coverage and long-lasting performance. Supplied cut to size up to 3200mm maximum length, it is suitable for a wide range of stair installations.

The AN61 is available in a range of finishes, including Black Anodised, as well as Bronze and Light Bronze options within our Designer Collection – ideal where the aesthetic of aged brass is desired without the premium cost. Matching flooring trims are also available within the Designer Home Collection.

Choose from a variety of high-performance infill options including:

Castellated PVC (SRV Wet: 76 / Dry: 85)
Smooth Textured PVC (SRV Wet: 56 / Dry: 65)
ATI49.5 Aluminium Insert (SRV Wet: 54 / Dry: 82)
Olympic Grip (SRV Wet: 71 / Dry: 102)

The interlocking back edge allows compatibility with:

ANRE25 Ramp Extension
ANEXT Tread Extender
ANE Nap Detail (for broadloom carpet)

For external or high-slip-risk environments, the AN61 is also available in Mill Aluminium with GRPTI49.5 glass-fibre reinforced plastic insert for enhanced slip resistance (Product Code: AN61 GRP).

Suitable for low to medium traffic staircases. Please note that heavy impact may wear the surface finish over time, revealing the natural aluminium beneath.

Dimensions may vary by up to ±5mm in line with supplier manufacturing tolerances.

**1.0m, 1.5m and 2.0m are custom cut lengths to order. As such these are non returnable except where there is a fault. This does not affect your statutory rights**

Oops we are still working on this - please check back soon

Catalogue Reference	AN61BA
Uniclass2015	Pr_35_90_31_74 RIGID STAIR NOSINGS
General Description	Single Channel/Raked Front Stair Nosing. Supplied with choice of infill.
Nosing Construction	Stair Nosing With Infill
Material	Aluminium Alloy 6063 T6
Tread Dimension	62 mm
Nose Dimension	32 mm
Gauge	5.0 mm
Supplied Cut To Size, up to a maximum length of	2700 mm, 2750 mm, 3200 mm
Screw Size	8
Compatible Products	ANEXT, ANRE25
Application	ANRE25 Ramp Detail and ANEXT extension tread installation guide available. Suitable for stairs with low to medium traffic volumes where heavy foot traffic and impacts may cause wear., flush in wooden steps. Compatible with profiles ANE Nap Detail
Suitability	through the finish to reveal the natural aluminium colour beneath.
Post Consumer Recyclability	This product is 100% recyclable at suitable disposal centres.
Profile Type	Stair Nosing

What floor coverings is the AN61 suitable for?

The AN61 is designed for use with carpet and carpet tiles and can also be rebated into timber steps for a flush finish.

Is the AN61 suitable for external use?

Yes, when specified as the AN61 GRP version with glass-fibre reinforced plastic insert for enhanced slip resistance in wet or outdoor areas.

What is the maximum length available?

The AN61 is supplied cut to size up to a maximum length of 3200mm.

What traffic level is this stair nosing suitable for?

It is recommended for low to medium traffic environments. For heavy-duty applications, the Mill Aluminium GRP version is advised.
